TECHNOLOGY FOCUS

We will discuss the modern digital modulation techniques and multiple access techniques of the physical (or radio) interface of all digital communication systems

Techniques such as OFDM, OFDMA, SOFDMA, SC-FDMA, DMT, MIMO, Massive MIMO, BLAST, CPM modulations (e.g., GMSK), and adaptive modulation and coding methods will be discussed. These techniques are used in broadband wireless communications, e.g., 5G-NR (based on 2n OFDM numerology), 4G-LTE and IEEE802.11. These methods are also in use in wireline systems such as ADSL and DOCSIS, as well as space and satellite communications. We will place special emphasis on the CP-OFDM modulation which is the standard for 5G-NR.

Recently there have been a number of new OFDM-based proposals, e.g., GFDM, and FBMC for the modulation of 5G. There have also been other new 5G modulation proposals based on "Faster-Than-Nyquist" (FTN) signaling, Wave Modulation (WM) and Spatial Modulation. We will describe the concepts and techniques described above, including their use in the systems described above.

We will also describe some of the important results of Shannon Information Theory, which are the basis for almost all communications.

Modern Digital Modulation
Modern Digital Modulation

COURSE CONTENT

We will describe the digital modulation techniques used in present major wireless and wireline communication systems and for those systems being planned, for the future. During the course we will discuss the challenges of the future Fifth Generation (5G) cellular systems. These systems, which are scheduled to appear commercially in the very near future. will challenge our present concepts and technologies. The 5G systems will utilize many of the concepts to be discussed in the course.

We begin the course with a discussion of the characteristics of major communications channels with special emphasis on the fading channel of wireless communications. We continue with a description of the classic modulations, e.g., Nyquist signaling, QPSK, QAM (and Offset QAM), CPM and GMSK, and the optimum receivers for these modulations. We will place special emphasis on OFDM and its related multiple access techniques, e.g., OFDMA, SOFDMA, SC-FDMA. This discussion will include a description of the radio interfaces of 5G-NR, 4G-LTE, and IEEE802.11 (Wi-Fi). We will also discuss some of the new OFDM-based proposals for 5G as well as other proposals for new modulations for future 5G systems, including "Faster-than-Nyquist" (FTN) signaling, Wave Modulation (WM), Spatial Modulation and the OTFS (Orthogonal Time Frequency and Space) modulation.

We will cover the space, time and frequency diversity techniques used in new wireless systems with special emphasis on MIMO, BLAST and Massive MIMO techniques. Massive MIMO is one of the major elements of the standards for 5G systems.

Other important subjects to be covered, are Alamouti space-time coding, iterative techniques, and adaptive modulation and coding.  We will also discuss the very important limits on communications based on Shannon’s information theory. These limits are the basis for coding, OFDM, MIMO and other important results. Coding techniques including convolutional coding, turbo-coding, and LDPC codes will be described.

We will also discuss constant envelope (CPM) modulations, e.g., GMSK and MSK, which are still important modulations for wireless and space communications. And finally, we finish the course with a description of CDMA, a major multiple access technique, which was used in Second and Third Generation Cellular Systems.

After participating in this course, you will:

  • Understand the modulations and multiple access techniques in use in modern mobile wireless (including satellite communications), broadband access and wireline communications, especially 5G-NR.
  • Understand the OFDM, OFDMA, Scalable OFDMA (SOFDMA), SC-FDMA modulations as well as their implementation based on DMT
  • Understand the performance of classic modulations such as QPSK and QAM, as well as the CPM modulations, e.g., GMSK
  • Understand the space, time and frequency diversity techniques of wireless communications e.g., MIMO, Massive MIMO, BLAST, and Alamouti Coding
  • Be familiar with the radio (or physical) interfaces of the 5G-NR, 4G-LTE and IEEE802.11 systems
  • Understand the challenges faced by the planners of the Fifth Generation (5G) systems and the possible solutions to these challenges
  • Understand some old ideas like Offset QAM and "Faster-than-Nyquist" Signaling, which may be used in new 5G systems.


WHO SHOULD ATTEND

The course is aimed at engineers, scientists and algorithm developers who are interested in digital modulation and multiple access techniques for modern wireless and wireline communications.

The course should be of interest to those people who want to know about the OFDM (and OFDM-based modulations), MIMO and Massive MIMO techniques in use in 4G and 5G-NR.

The course should also be of interest to those who want to know more about constant envelope modulation techniques, e.g. GMSK.

Modern Digital Modulation

Day 1

Rayleigh Fading Channel and Baseband Nyquist Signaling

The course begins with a description of the channel models for mobile wireless and wireline systems. This is followed by discussions of Nyquist baseband signalling, as well as ISI and linear equalization.

  • "A Bit of History"
  • Discussion of the Challenges Facing the Fifth Generation (5G)
  • Introduction to Analog and Digital Communications
  • System Model-The Channel
  • The Multipath Channel (Rayleigh, Delay Spread and Frequency-Selective Fading)
  • Introduction to Diversity Techniques-Antenna Diversity and Coding
  • Twisted-Pair Channel

Brief Review of Fourier Transform, Power Spectral Density, White Noise

Nyquist Signaling

  • ISI, Optimum Filtering, Square-Root Nyquist Filtering, Linear Equalization
  • Partial Response Signals-Why the MLSE and the Viterbi Algorithm?
  • What is "faster-than-Nyquist" Signaling?


Day 2

Signal Space, Optimum Detection

The concept of signal space is used to define the classical modulation techniques and derive the optimum detectors.

Signal Space, Optimum Detection

  • Signal Space
  • BPSK, QPSK, MPSK, QAM, BFSK and MFSK-Definitions
  • Optimum Detection of Binary Signals and Probability of Error
  • Matched Filter

The Rayleigh Fading Channel and Antenna Diversity-BLAST, MIMO

An in-depth discussion of the performance of modulations, transmitted over Rayleigh fading channels, followed by a discussion of the concept of space diversity (BLAST, MIMO and Massive MIMO), which is used to greatly improve spectral efficiency.

  • Detectability Performance of BPSK over Rayleigh Fading Channel (SISO)
  • Classic Antenna Diversity (SIMO)
  • Space Diversity
  • MIMO
  • BLAST
  • Massive MIMO-What is it? What can be gained?

Day 3

MSK-type Signals

QPSK, SQPSK, and MSK are essentially constant envelope modulations, which are used in many satellite and wireless systems.

  • QPSK, SQPSK, pi/4 - QPSK, EDGE "8PSK"
  • MSK-type (MSK, SFSK) Signals
  • Adjacent Channel Interference (ACI)

M-ary Signals

M-ary signals are used in many systems, e.g., analog modems, ADSL, VDSL, microwave radio, and are the basic modulation of almost all OFDM systems.

  • Optimum Detection of M-ary Signals
  • MPSK
  • Quadrature Amplitude Modulation (QAM)-Nyquist Signaling
  • Offset QAM-OQAM- 5G Modulation Proposals
  • MFSK

Shannon Information Theory

Shannon information theory is the basis behind coding, analog modems, ADSL, multitone modulation (DMT), OFDM, and adaptive modulation and coding. OFDM (DMT) is the modulation for 5G-NR, 4G-LTE, IEEE 802.11 (Wi-Fi), as well as ADSL and VDSL. We present an in-depth discussion of multitone modulation, DMT, OFDM, OFDMA, Scalable OFDMA and SC-FDMA. Then we will discuss the Radio Interfaces of 5G-NR, 4G-LTE and IEEE802.11., which are all based on OFDM.

 Introduction to Shannon Information Theory

  • Channel Capacity for Ideal and General Gaussian Channels

Multitone-DMT

  • Discrete Multitone (DMT) - Implementation
  • The Twisted Pair Channel
  • Multitone (DMT) over the Twisted Pair Channel (ADSL and VDSL)

OFDM-Orthogonal Frequency Division Multiplexing

  • OFDM - for Broadband Wireless Communications
  • Adaptive Modulation and Coding Techniques
  • OFDMA as a Multiple Access Technique
  • Scalable OFDMA

Physical Interfaces of IEEE 802.11 (Wi-Fi), 4G-LTE and 5G-NR (including 2n numerology)

  • SC-FDMA (Single-Carrier FDMA-4G-LTE)
  • OFDM-MIMO

Day 4

5G-Proposals based on OFDM

  • Offset QAM in OFDM Systems
  • Universal Filtered Multi-Carrier (UFMC)
  • Filter-Bank Multi-Carrier (FBMC)
  • Generalized Frequency Division Multiplexing (GFDM)
  • Filtered OFDM (f-OFDM)

Trellis Coding, Convolutional Coding and The Viterbi Algorithm

We continue with a description of trellis coded modulation concepts and convolutional coding, including a discussion of the Viterbi Algorithm. We also include the topic of interleaving for improving the performance of modulations on Rayleigh fading channels.

  • The Viterbi Algorithm (VA)
  • Ungerboeck Trellis Coding
  • The VA Equalizer
  • Interleaving for Rayleigh Fading
  • Performance on the Rayleigh Fading Channel
  • Convolutional Coding

"Faster-Than-Nyquist (FTN) Signaling"

  • What is FTN?
  • What is its performance?
  • Candidate for 5G

Turbo-Coding-Introduction

A topic of increasing importance is the turbo-coding (iterative decoding) concept and its use in areas such as antenna diversity, equalization and OFDM.

  • Turbo Coding
  • Iterative Decoding Techniques
  • Turbo-Equalization
  • Introduction to LDPC Codes

Capacity of Rayleigh Fading Channels

Shannon's work has been updated to include bounds on the performance of Rayleigh fading channels. This work led to the concept of MIMO and space-time (Alamouti) coding.

  • Bounds on Communications for Fading Channels
  • OFDM-MIMO-Coding
  • Space-Time Coding
  • Alamouti Coding
  • Multi-User Diversity Techniques

Day 5

Continuous Phase Modulations (CPM)

CPM signals (e.g., GMSK) are constant envelope, bandwidth efficient modulations, suitable for use with nonlinear power efficient, transmitting power amplifiers. These modulations are used in GSM and deep space communications.

  • Continuous Phase Modulation (CPM)
  • Gaussian MSK (GMSK)
  • Tamed FM (TFM)
  • Generalized TFM (GTFM)
  • Constant Envelope OFDM
  • Adjacent Channel Crosstalk in CPM Signals

Non-Coherent Detection

  • DPSK
  • FM Detection of CPM Signals-Bluetooth, DECT

Other New Modulation Proposals for 5G

  • OTFS-Orthogonal Time Frequency Space Modulation
  • Wave Modulation
  • Spatial Modulation

CDMA and WCDMA

We continue with a discussion of CDMA and WCDMA, and describe the radio interfaces of the IMT-2000 WCDMA system, as well as the physical interface of IS-95.

  • The RAKE Receiver
  • Pseudo-Random Sequences
  • Power Control
  • Intra and Inter-Cell Interference and Capacity
  • IS-95 Physical Interface
  • IMT-2000 WCDMA Physical Interface: Walsh and OVSF Functions
